Rebelcell 29.4V07A RANGE EXTENDER

1.945,00lei



    •  Compatible with: (outboard) engines with 12V alternator with at least 17A charge current. Compatible with all known brands (e.g. Honda, Mercury, Yamaha, Suzuki etc.).
    •  In your package: 1x Range Extender 29V, 1x connecting cable set (with extra fuses + connector).
    •  Charge indicator: if the LED is ‘ON’ your battery is being charged.
SKU: DC24V07REPK Categorie:
  • Descriere
  • Recenzii (0)
Description

MAIN FEATURES

  • COMPATIBLE WITH (outboard) engines with 12V alternator with at least 17A charge current. Compatible with all known brands (e.g. Honda, Mercury, Yamaha, Suzuki etc.).

  • OPTIMAL CHARGING PROFILE provides the correct charging profile (charge voltage and current) to safely charge your Rebelcell 24V battery.

  • STARTER BATTERY DISCHARGE PROTECTION continuously monitors the voltage in the starter battery and will only allow charging of the 24V battery if starter batter voltage is above 13.2V. This ensures that the starter battery is not accidentally discharged.

  • OVERCHARGE PROTECTION will automatically adjust the alternator output charge current to avoid overcharging of your battery.
  • TEMPERATURE PROTECTION the ‘dynamic thermal output control’ limits the charge current to reduce the temperature.

  • SHORT CIRCUIT / REVERSE POLARITY PROTECTION automatic shutdown with short circuit. Reverse polarity protection on input .

  • CHARGE INDICATOR if the LED on the Range Extender is ‘ON’ your battery is being charged.

  • WARRANTY two years.

NEW! model 2022 The Range Extender (model 29.4V7A) allows you to extend your fishing day by recharging your Rebelcell 24V AV battery ‘on the go’ via the alternator of your (outboard) engine.

The Range Extender continuously monitors the voltage in the starter battery to prevent accidental discharge, limits the alternator current if required and provides the correct charging profile (voltage, current) to safely charge your 24V battery. Thanks to the built-in charge indicator you can easily see if your battery is being charged.



IMPORTANT INFO

PLEASE REVIEW THE BELOW INFORMATION BEFORE COMPLETING YOUR ORDER



DETAILS & SPECIFICATION

TECHNICAL SPECIFICATIONS

Capacity

200W

Galvanic seperation

Yes

Input voltage range (alternator output)

9 – 18V

Output voltage

29.4V

Output Ripple & Noise

<50mV RMS

Peak efficiency

max 95%

Parallel connection

No

Temperature range

-20°C tot +30°C (linear lowering of charge current to 0°C @ 70°C)

Humidity (non condensing)

max 95%

Dimensions

176 x 88 x 50 (mm)

Weight

0.6 kg

Charge indicator

Yes, via LED

Connectors input / output

Non-isolated yellow AMP connector (Quick Connect M 6.3 mm)

BESCHERMING

Overcharge / short circuit

Yes, output

Over voltage

Yes, input and output

Reverse polarity protection

Yes, input

Reverse polarity protection

Yes

Input fuse

30A inline (+cable)

Output fuse

10A inline (+cable)

CERTIFICATION

CE

Yes

Automotive



EMI/EMC

EN50081-1 (EMI), EN50082-1 (EMC), European Automotive Directive 95/54/CE

Warranty

Two years

EAN

7106623691915

Product code

DC24V07REPK

HS code

85044030
