GALA ATLANTIS AQUAHELM A390HQ

Overview

ATLANTIS Aquahelm A390Q ORCA Hypalon tube

The AQUAHELM for GALA boats is THE IDEAL SOLUTION if you are looking for the lightest tender with remote steering. Four GALA models, available at Boats Expert in Romania, can be equipped with the innovative AQUAHELM S-08 steering console & seat combo. Designed by GALA, this console is extremely light and versatile with slim, eye-catching outlines, easily converting your dinghy into an unbeatable center console. Available as an upgrade for models A300D, A330D, A360D, and A390D, the console can be installed anytime, allowing you to upgrade from classic tiller drive to remote control steering. You can also adjust the console and arm positions for your comfort.

GALA Tabs are a unique feature created and patented by GALA, significantly improving performance and making it easier to get on plane than any other boats on the market. The AQUAHELM console boasts an elegant and slick design, with ample interior room for various equipment. The AQUAHELM concept provides an incredible amount of free cockpit space, especially offering LEG ROOM for the driver and passengers. Each GALA Atlantis-AQUAHELM model is extremely lightweight, making them an unbeatable choice if you need a really light boat with remote steering.Each boat is equipped with the advanced Overpressure Valve for protection against overheating and over-inflating.

Standard Features

Medium-V, powder-coated aluminum hull with antiskid decking and hidden reinforced transom brackets.
«GALA TABS» – special patented GALA hull design with transom extensions.
Spacious bow locker with access hatch.
Soft bow locker cushion with close cell foam.
AQUAHELM S-08 double seat with steering arm, soft cushion, folding set back and storage.
Steering wheel with steering cable and wheel.
One aluminum seat with sliding installation system.
Substantial keel protector.
4 lifting eyes and 3 towing bow eyes.
Bow handle and two rear handles.
GALA bow cleat and 8/10 grab handles.
Soft curved 3-chamber PVC or Hypalon buoyancy tube with rounded bow and original «GALA-JET» design.
Overpressure valve.
Tough rubbing strake with splash guard.
One-way drain valve with pull-up handle.
Two collapsible paddles.
High-efficiency foot pump.
Repair kit and manual.

Optional Equipment

Overall cover.
Electric package.
SEADECK flooring upgrade.
SILVERTEX upholstery upgrade.
Seat cover.
Bow step plate.
Upgrade to 20″ high transom for long shaft motors on A360Q, A390Q.
GPS installation bracket.
Removable fishing panel with 2 rod holders.

SPECIFICATIONS

Length overall	390 cm / 12’10”
Length inside	310 cm / 10’2″
Width overall	170 cm / 5’7″
Width inside	82 cm / 2’8″
Tube Diameter	44 cm / 17″
Bare boat weight	115 kg / 253 lbs
Loading capacity	650 kg / 1430 lbs
Passenger capacity	6
Number of chambers	3
Engine recommended	20 HP
Engine MAX	30 HP
Engine weight MAX	70 kg / 154 lbs
Engine shaft length	15″ (short) / 20″ upgrade
Aluminum hull thickness	3 mm / 1/8″
Boat design category	C

Length overall	3,9 m
Beam	1,7 m
Deadrise at transom	-
Draft	-
Transform height	382 mm (S)
Hull material	Aluminum
Hull thickness	3 mm / 1/8″
Boat weight	115 kg
Max weight capacity	650 kg
Engine	30 HP
Fuel tanks	-
Livewell	-
Persons	6
Road storage	-
